Fixed unit offering large sightlines and strong energy efficient performance with large and small profiles.
Fill out my online form.
Small and large frames allow for matching sightlines for a variety of configurations all in a 3 1/4" frame. Contoured sash creates a millwork look and allows up to 1 3/8" triple pane insulated glass. Small Picture Window/Large Picture window test data below:
| Dual Pane Lo-E 180 |
Dual Pane Lo-E 272 |
Dual Pane Lo-E 366 |
Triple Pane Lo-E 272 |
Triple Pane Double Lo-E 272 |
|
| U-Factor | 0.28/0.27 | 0.27/0.26 | 0.26/0.26 | 0.20/0.20 | 0.15/0.16 |
| SHGC | 0.55/0.49 | 0.35/0.31 | 0.23/0.21 | 0.33/0.29 | 0.30/0.27 |
| VT | 0.67/0.60 | 0.61/0.54 | 0.55/0.49 | 0.56/0.50 | 0.49/0.43 |
| Condensation Resistance |
N/A | N/A | N/A | N/A | N/A |
| AI | <0.01 cfm/ft2 | ||||
| Water Resistance |
N/A | ||||
|
Design
Pressure
|
N/A | ||||
| Frame | Rehau uPVC |
| Frame Size | 3-1/4 |
| Exterior Colors | Almond, Black, Brick Red, Bronze, Brown, Clay, Dakota Sand, Forest Green, Gray, Mocha, White |
| Interior Colors | Almond, Black, Clay, Dark Woodgrain, Heartwood, Irish Oak, Maple, White |
| Grille Colors | All interior and exterior colors available and brass |
| Grille Type | Flat, Contour, Slimline |
| Grille Pattern | Colonial, Prairie, Farmhouse, Suspended |
| Brickmold | Standard, Retro, Wide |
| Glass Strength | Annealed, Tempered |
| Glazing | Interior |
| Glazing Type | blink BLINDS + GLASS w/ LoE 272, Dual Pane LoE 180/Argon, Dual Pane LoE 272/Argon, Dual Pane LoE 366/Argon, Triple Pane LoE 272/Argon, Triple Pane-Double LoE 272/Argon, Dual Pane-272/Argon Clear |
| IG Thickness | 1" oa. dual pane, 1 3/8" oa. triple pane |
| Angle of Deflection | n/a |
| Spacer | Endur |
| Interior Returns | Jamb, Drywall |
| Extension Jamb Loose | Almond (8"), Black (8"), Dark Woodgrain (8"), Heartwood (8"), Irish Oak (8"), Maple (8"), White (4", 8") |
| Extension Jam Applied | Almond, Black, Dark Woodgrain, Heartwood, Irish Oak, Maple, White |
| Maximum Frame Width | 120 |
| Minimum Frame Width | 10 |
| Maximum Frame Height | 120 |
| Minimum Frame Height | 10 |
